SmartCloset TM

SmartCloset™ is the new standalone self-contained rack from Features and Benefits

Vertiv, along with inbuilt power and cooling. It facilitates the
housing and trouble-free installation of active IT equipment y y Dedicated Rack mount

like switches, routers and so on - for which, an open cooling - The air conditioner
capacity is designed
environment is not conducive for healthy performance. considering only rack
equipment load and rack
volume, thus saving on both
Compact and powerful with inbuilt power and cooling. capital and operating costs.

SmartCloset™ is suitable for any location like factories, warehouses, branch offices and y y Rack mount UPS and Battery
retail stores where ambient conditions and temperatures are not in control; and also - A single rack for housing
where dust and dirt are common. both power and active
equipment offers lesser
footprint and saves on critical
C19" RACK COOLING COOLING REMOTE space area.
15U/24U/42U Side panel mount CAPACITY MONITORING
Air-conditioner Up to 2KW Optional y y High sensible cooling and
24x 7 application -
As IT equipment is designed to
run 24x7 and typically dissipate
sensible heat load,
SmartCloset™ is exclusively
designed for such applications
to deliver maximum efficiency.

y y Cooling unit with safety
features -
The air conditioner comes with
HP/LP switch and Under/Over
voltage protection for sites at
remote locations and with high
voltage fluctuations.

y y Rack Monitoring -
(Optional feature)
UPS AVAILABLE BATTERY RACK PDU Rack environment monitoring
3/6 kVA USABLE SPACE For 10 mins Vertical & Horizontal like temperature, humidity, door
Up to 11/16/32U mount with suitable IEC sensor, smoke sensor, etc.
13 and IEC 19

SmartCloset Configuration
TM

Specification SCL -15 P* #** SCL - 24 P* #* * SCL - 42 P* #**
Rack Height 15U 24U 42UP-
UPS Capacity (P)* NA External 3/6 kVA
BatteryMin NA External 10 mins
Usable U space 11 16 32

Cooling Capacity # (Watts) * * 500 500 / 1000 500 / 1000 / 2000

While ordering
# X Y Z Order sample
500 1000 2000 SCL 15 1 X, SCL 24 3 Y......
